Product Details
The Zhukov-S Stock attaches to most stamped AK receivers using the included unique wedge block geometry and adds side-folding capability, LOP adjustments, and other upgrades to customize and modernize your Kalashnikov. The firearm can be charged and fired with the stock folded without the cheek riser installed. Folds to right side to not obstruct common left-side AK optics mounts. Counts as one part for 922(r) compliance. Made in the USA. Features The Zhukov-S uses unique wedge block geometry for a secure fit with most stamped AK receivers Provides a secure right-side folding capability that allows charging and firing from the folded position when cheek risers are not installed The folding lock mechanism uses a solid steel hinge to secure the folded stock into place, but still allows the stock to deploy quickly and easily Allows quick LOP adjustments through five positions and locks securely into place, providing a "fixed stock" lockup in during use Adjustment latch is shielded to prevent unintentional activation Slim cheek weld provides extra comfort for the shooter Accepts Magpul AK Cheek Risers for a more custom fit and proper eye alignment with optics The angled, anti-slip rubber butt-pad absorbs recoil and includes a rollover toe for fast shoulder transitions and a better fit in body armor The optional QD sling sockets on left side of folding mechanism and on both sides of stock’s rear plus the footman’s loop provide different sling mounting options ANGLED RUBBER BUTT-PAD Offers an anti-slip surface and increases impact protection, and the rollover on the toe allows for easier shoulder transitions and a better fit when using body armor POSITIVE RETENTION IN THE FOLDED POSITION High strength, wear-compensating lock mechanism with a solid steel hinge pin allows stock to fold to the right OPTIONAL QD SOCKET AND CHEEK RISERS With sling loop for additional mounting options Cheek weld combines a slim profile with user comfort and optional snap on AK Cheek Risers are available for use with optics ADJUSTABLE LENGTH OF PULL 5-Position length of pull adjustability and solid "fixed stock" lockup with consistent cheek weld in all positions Anti-snag adjustment lever, and the positive detents in the stowed position prevent movement while still allowing the stock to be instantly deployed. Firearm may be charged and fired while stock is folded (without Cheek Risers installed) SLING OPTIONS Front - Left-side rotation limited sling mount accepts push-button QD swivels for one-point sling usage (swivel not included) Rear - Optional Sling Mount Kits ( TYPE 1 and TYPE 2 ) accept push-button QD swivels Bottom - 1.25" sling loop
Technical Specifications
| Platform |
AK / AKM |
| Compatibility |
Most stamped receiver AK-47/AKM/AK-74 pattern rifles with fixed stock, single tang trunnion |
| LOP Adjustment Range |
2.6 in. |
| Length |
8.8-11.4 in. |
| Weight |
15.0 oz. |
| Other Specs |
LOP Adjustment: 5 |
| Position |
(0.65"/position) LOP, Collapsed: ~12.2 in. LOP, Extended: ~14.8 in. *NOTE: Due to the wide range of tolerances of your typical AK, minor fitting of the stock may be required. Not compatible with Yugo pattern AKs or the Norinco |
| Type |
56S / MAK-90 due to differences in the trunnion’s tang. Not compatible with traditional milled-receiver rifles. **Specifications based on factory configuration |
Additional Resources
MAG585 ZHUKOV-S Stock Installation Instructions
